FEATURES
Aero Family Plus provides consistent drug delivery time after time and can be use for all the commonly prescribed respiratory medications. The device is capable of generating a medication mist of particles that are small enough to reach even the deepest regions of your lungs and the maximal benefit. All the common liquid medication can be used for inhalation therapy.
FUNCTION
Technical specifications: | |
Nebulisation rate | 0.3 ml/min.(3 ml inhalation takes less than 10 minutes) |
Particle size | 1.9 μ m (MMAD with 0.9% NaCl using API system) or 4.48 μ m (MMD WITH Salbutamol using Malvern system) |
Compressor air flow | 9 l / min |
Acoustic noise level | 58 dBA |
Power source | 230V / 50 Hz (for model 92400), 115V / 60Hz (for model 92402) |
Compressor MAX pressure | 230 kpa (2.3 bar for model 92400), 33 psi (for model 92402) |
Power cord length | 2 m |
Operating temperature and humidity | 10℃ –40 ℃, 10% — 95% relative humidity maximum |
Storage temperature and humidity | -25℃–+70 ℃, 10%–95% relative humidity maximum |
Operating limits | 30 min. ON / 30 min. OFF |
Weight | 1.56 kg |
Size | 195 mm x 160 mm x 105 mm |
COMPONENTS
- Compressor housing
- ON / OFF switch
- Power cord
- Air outlet
- Filter holder
- Nebulizer holder
- Air vent openings
- Handle
STANDARD ACCESSORIES
- Nebulizer
- Mounthpiece
- Air tube
- Nosepiece
- Spare air filter
- Carry case
- Adult mask
- Pediatric mask
